| Brand Name : | thompson |
| Model Number : | HOG2B |
| Price : | negotiable |
| Payment Terms : | L/C, T/T |
| Supply Ability : | 200,000 meter per month |
| Delivery Time : | 15-20 working days |
Hydarulic hose Structure
wire braid hydraulic hose Consists of inner tube, middle layer, one or two wire reinforcements and cover. Inner tube is to transmit liquid under pressure and protect wire against corrosion while cover is to protect wire against abrasion, wire layer is the structure materials that providing reinforcement.
Hydralic hose application
wire braid hydraulic hose Mainly used in mine hydraulic support, oil exploration, suitable to engineer construction, crane transport, forging metallurgy, mining equipment, ships, injection molding machinery, agricultural machinery various machine tools.
Hydraulic hose working temperature
-40°C to +100°C
| DN | Hose I.D | Hose O.D | WorkingPressure | Burst Pressure | Minimum Bend Radius | Weight | Length | ||
| inch | mm | mm | MPa | MPa | mm | kg/m | meters | ||
| 5 | 3/16 | 4.8 | 13.3 | 45 | 180 | 90 | 0.325 | 20-100 | |
| 6 | 1/4 | 6.4 | 14.3 | 40 | 160 | 100 | 0.384 | 20-100 | |
| 8 | 5/16 | 7.9 | 16.2 | 35 | 140 | 115 | 0.460 | 20-100 | |
| 10 | 3/8 | 9.5 | 18.3 | 33 | 132 | 130 | 0.551 | 20-100 | |
| 13 | 1/2 | 12.7 | 21.3 | 27.5 | 110 | 180 | 0.667 | 20-100 | |
| 16 | 5/8 | 15.9 | 24.8 | 25 | 100 | 200 | 0.822 | 20-100 | |
| 19 | 3/4 | 19.1 | 28.5 | 21.5 | 86 | 240 | 1.020 | 20-100 | |
| 25 | 1 | 25.4 | 36.3 | 16.5 | 66 | 300 | 1.380 | 20-50 | |
| 32 | 1 1/4 | 31.8 | 46.5 | 12.5 | 50 | 420 | 1.895 | 20 | |
| 38 | 1 1/2 | 38.1 | 52.6 | 9.0 | 36 | 500 | 2.120 | 20 | |
| 51 | 2 | 50.8 | 65.6 | 8.0 | 32 | 630 | 2.765 | 20 | |
|
|
